Hillside Mowers
Versatile Working Attachments for Multi‑purpose Operations
The flail head comes as standard equipment, featuring a 1400mm rotor width. The Y‑flails are capable of cutting weeds and light wood with a diameter of ≤30mm. The cutting height offers three adjustable positions ranging from 30mm to 90mm; it can also be set to higher than 90mm by lifting the flail head.
Equipped with an auto‑float function, the flail head can follow ground contours with a vertical swing angle of 10°, ensuring a uniform cutting finish.
Optional attachments include a mulcher and a branch crusher. The mulcher can process wood with a diameter of ≤100mm, while the branch crusher has a maximum crushing capacity for materials up to 120mm in diameter. These attachments enable the machine to perform various tasks such as mowing, wood chipping, and branch crushing.
All attachments share unified hydraulic parameters (flow rate: 84L/min; pressure: 250bar), which ensures high compatibility with the host hydraulic system and allows for quick and easy attachment changes.
Product Introduction
English Translation (for Foreign Trade)
The Smartiger Hillside Mower is a professional-grade machine designed for complex steep-slope operations, boasting comprehensive functions and high safety performance. Based on its technical specifications, its core advantages and features are as follows:
Exceptional Steep-slope Operation Capability for Complex Terrain
Equipped with heightened-tooth rubber tracks, it achieves a maximum working gradient of 55° and supports operation on slopes in any direction, far exceeding the terrain adaptability limits of conventional mowing equipment.
Built-in slope warning and protection mechanism: an audible and visual alarm is triggered when the tilt angle reaches 50°, and automatic shutdown is activated at 55°, fundamentally eliminating rollover risks during steep-slope operations.
Adopts skid-steering with pivot-steering support, combined with travelling bias correction function, ensuring precise control of travel routes even on steep slopes.
Powerful and Stable Power & Hydraulic Systems for High Operating Efficiency
The power core is a YANMAR 3-cylinder 4-cycle inline water-cooled diesel engine, compliant with the European III emission standard, with a rated gross output of 28.2Kw (38.3Hp) @2600rpm, delivering abundant power while being eco-friendly.
The hydraulic system features high-end configurations, including a Bondioli & Pavesi 3-tandem piston pump + 2 gear pumps, matched with Poclain high-torque driving motors and Danfoss high-speed flail mower motors, ensuring rapid power response of all executive components.
Two-speed travel adjustment is available: the low range (1st gear) supports forward and reverse travel at 0–4 km/h for precision operations, while the high range (2nd gear) enables 0–10.2 km/h forward and reverse travel to boost relocation efficiency. It is also equipped with a one-click release cruise control system.
Flexible Remote Control for Wide-ranging and Convenient Operation
Equipped with a 2.4G wireless remote control system with an effective operating range of over 150m, allowing operators to stay away from hazardous work areas and ensuring personal safety.
Comes with interchangeable and rechargeable batteries—two batteries are supplied with each unit, and charging can be done directly on the machine, avoiding operation interruptions caused by dead batteries. The remote control features proportional joysticks as standard for high-precision manipulation.
Comprehensive Safety Protection for Reliable Operations
Equipped with multiple safety protection mechanisms, including a one-touch emergency stop switch, automatic shutdown upon signal loss, and automatic shutdown when abnormal pressure is detected in hydraulic oil and lubricating oil, covering multiple safety dimensions such as operation, signal transmission and hydraulic system performance.
Fitted with LED headlights to meet night operation requirements; the built-in parking function prevents the machine from sliding when parked on steep slopes.
Compact Design with Optimized Weight Distribution
The main unit weighs only 1250Kg, and the total weight is approximately 1630Kg when equipped with the standard flail head. With an overall width of 1500mm (with flail head) and an overall height of 1300mm (with flail head), the compact size makes it suitable for operations in narrow spaces.
Product Details
Features high-performance hydraulic hoses from Continental (Germany) or Yokohama (Japan), ensuring outstanding durability and reliable operation under demanding conditions. |
| Fitted with heavy-duty rubber tracks that include reinforced anti-slip treads, delivering superior traction and reliable mobility. |
|
| The bi-directional cooling fan system maintains ideal operating temperatures while automatically clearing dust buildup for continuous performance. |
| The mulching head is fully remote-controlled and offers stepless speed adjustment along with smooth forward/reverse rotation. |
Technical Parameters
Parameter | Specification | Parameter | Specification |
Model | HYZH-40 | Pressure | 250bar |
Engine Brand | YANMAR | Headlight | LED |
Fuel | Diesel | Tool Rotation Speed | 2500rpm |
Fuel Tank Capacity | 28L | Tool Rotation Direction | Forward and reverse (bidirectional 0-100% stepless adjustable) |
Torque | 107.1Nm | Control of Attachment Front Cover Opening/Closing | Remote control |
Fuel Injection Method | Direct injection | Tool Material | Tungsten steel |
Rated Power | 28.2Kw | Working Width | 1200mm |
Transmission Mode | Hydrostatic precision control | Number of Tools | 27 |
Cooling Method | Oil-air hybrid cooling | Crushing Diameter | 100mm |
Vertical Obstacle Crossing Height | 500mm | Forearm Lifting Height | -200mm to 500mm |
Wading Depth | 500mm | Supported Slope | Meets working conditions with a slope angle of 55° |
Departure Angle | 30° | Dimensions | 3230mm × 1450mm × 1420mm |
Straight-line Deviation Angle | 0.3% | Self-weight | 1840kg |
Topsoil Backfilling Depth | 20mm | Maximum Traction Force | 25KN |
Working Distance of Remote Control System | >150m | Ground Clearance | 170mm |
Allowed Operating Inclination Angle | 60° in any direction (after engine optimization) | Attachment Terrain Matching | Yes (matches terrain undulations within ±10°) |
Hydraulic Pump | Piston pump + gear pump | Steering | Skid steering, supporting in-place steering |
Drive Motor | High-torque motor | System Allowed Operating Inclination Angle | ≥80° in any direction (after hydraulic system optimization) |
Hydraulic Tank Capacity | 26L (40L in the system) | Hydraulic Flow of Reclamation Attachment | 84L/min |
Stepless Speed Control | Working speed: forward/reverse 0-4 Km/h; Transfer speed: forward/reverse 0-10.2 Km/h | Parking Mode | Remote control. The parking switch ensures stable parking of the equipment. The parking knob enables on-site parking and electronic handbrake function, effectively ensuring safety, preventing sliding, and avoiding safety accidents caused by misoperation. |
Rubber Track (Standard) | High-tooth rubber track (supports 55° slope working conditions). Special working condition rubber track with teeth twice as high as ordinary/common tracks on the market, achieving strong grip, friction, and adaptability to various terrains | Proportional Joystick | Supports joystick direction switching for convenient operation when driving with the front or rear of the machine forward. Direction switching (forward/reverse) can be realized via the knob switch, which is more efficient without the need for U-turn. |
Frequency | 2.4G | Battery | 2 built-in rechargeable lithium batteries per unit, supporting self-charging |
Optional Attachments
Application Scenarios
Highway & Infrastructure Side Slope Care
Ensures safe and efficient trimming of grass, weeds, and brush on road embankments, medians, and tunnel entrances. With skid-steering and travel bias correction, operators can precisely control the mower via proportional joysticks, eliminating the need for personnel to work near traffic or unstable slopes. Signal loss and over-slope protection (automatic shutdown at 55°) further mitigate operational risks.
Ecological Restoration Projects
Facilitates the removal of invasive plant species in fragile ecosystems, promoting the recovery of native flora. The low-impact rubber tracks minimize soil compaction, while the closed-circuit hydraulic system ensures consistent performance even on slopes. The mulcher attachment (2500rpm rotor speed) processes cleared vegetation into organic mulch, supporting soil moisture retention and ecological balance.
Extreme Steep Slope Operations
Engineered for reliable performance on hillsides and mountains with slopes up to 55°. Integrated slope compensation and anti-tip systems trigger audible/visual alarms at 50° and automatic shutdown at 55°, preventing rollovers. The machine’s optimized weight distribution (1250Kg main unit + 380Kg attachment) and hydraulic lift (-200mm to 500mm) adapt to varying slope angles and terrain conditions, ensuring uniform cutting results.
This remote-controlled solution combines professional-grade power, precision, and safety, addressing the core challenges of steep-slope maintenance for B2B clients in agriculture, forestry, infrastructure, and environmental sectors worldwide.
Packaging & Shipping
To ensure the Forestry Mulcher, Lawn Mower with Track Chassis, hillside mowers, and Track Lawn Mower For Sale (track-equipped, market-ready) arrive intact and usable, we apply tailored packaging:
Base Protection: All units are wrapped in high-strength transparent plastic film (shields from dust, moisture, minor abrasions). For track-equipped machines (track lawn mower, lawn mower with track chassis, hillside mowers), anti-abrasion felt is inserted between treads (prevents rubber scratching); engines, control panels, and hydraulic systems are fully covered.
Pallet Securing: All are fixed on ISPM 15-compliant wooden pallets via galvanized anti-slip straps. Track-equipped machines are elevated 5–8cm with custom wooden spacers (avoids track deformation, enables safe forklift handling).
Reinforced Crates: All units are housed in 18mm plywood crates with steel corner reinforcements. Extra protections:
Forestry Mulcher: Extra bracing for mulching drum and engine (resists impacts);
Track-equipped machines: 40kg/m³ high-density foam cushions tracks/cutting decks; extra padding safeguards remote control receivers and electronics.
