40Pro Yanmar Lawn Mower
High Efficiency: Equipped with a high-power engine and professional mowing/shredding attachments, ideal for heavy-duty vegetation management in wastelands, forested areas, roadside slopes, and similar challenging environments.
High Flexibility: Remote-controlled operation keeps operators safely away from hazardous zones, making it especially suitable for steep slopes, marshes, and obstacle-filled areas that are difficult or dangerous for manual access.
High Reliability: Core components—including the Yanmar engine, Poclain motors, and Bondioli & Pavesi pumps—are from internationally renowned brands, ensuring exceptional durability and performance.
Product Introduction
Slope Lawn Mower Advanced Remote Control System
2.4 GHz wireless remote control with an effective range of over 150 meters.
Equipped with standard proportional joysticks for precise and smooth operation.
Includes two interchangeable, rechargeable batteries to ensure uninterrupted operation.
Professional-Grade Hydraulic and Travel System
Features a robust hydraulic system with a 3-tandem piston pump plus 2 gear pumps (Bondioli & Pavesi brand), ensuring powerful and stable performance.
Dual closed-circuit track drive powered by high-torque Poclain motors delivers strong traction and agile maneuverability, including zero-turn (pivot) steering capability.
High-lug rubber tracks provide excellent grip, ideal for challenging terrains such as muddy ground and steep slopes.
Multi-Attachment Compatibility
Standard attachment: 1400 mm flail mower head with Y-shaped flails, capable of cutting grass and light brush up to 30 mm in diameter; cutting height adjustable from 30 mm to 90 mm.
Optional attachments:
Mulcher: processes branches up to 100 mm in diameter.
Branch Crusher: handles material up to 120 mm in maximum crushing diameter.
All attachments are integrated via intelligent hydraulic flow allocation, ensuring efficient synergy with the main unit.
Product Details
Equipped with Continental (Germany) or Yokohama (Japan) hydraulic hoses for durability and reliability. |
| Fitted with heavy-duty rubber tracks featuring reinforced anti-slip treads for enhanced traction and stable mobility. |
|
| Dual-direction fan system with integrated cooling ensures optimal temperature control and automatic dust removal. |
| Remote-controlled mulching head with stepless speed adjustment and seamless forward/reverse rotation switching. |
Technical Parameters
Model | Smartiger | |
ENGINE | ||
Maker | YANMAR 3-cylinder(European V emission standard) | |
Type | 4-cycle, Inline, Water-cooled Diesel | |
Fuel tank capacity | 28 litres | |
Gross output | 28.2Kw (38.3Hp) @2600rpm | |
Self-cleaning(optional) | Standard manual and automatic (optional) | |
HYDRAULICS | ||
Pumps | 3-tandem piston pump + 2 gear pump | (Bondioli & Pavesi) |
Driving motors | High torque motor | (Poclain) |
Flail mower motor | High speed motor | (Danfoss) |
Independent flail head circuit | Closed circuit piston | |
Independent track drive circuit | 2x closed circuit piston | |
Independent motions circuit | Opend circuit gear | |
TRACKS | ||
Rubber | Hieghtened teeth rubber track (max working angle 55°) | |
REMOTE CONTROL | ||
Working range | >150m | |
Frequency | 2.4G | |
Battery | Interchageable, rechargeable | |
Two with each unit charge on machine | ||
Propotional Joysticks | Standard | |
DIMENSIONS | ||
Overall width (with flail mower) | 1500mm | |
Overall width (with flail mower) | 2900mm | |
Overall height (with flail mower) | 1300mm | |
WEIGHT | ||
Smartiger | 1250Kg | |
380kgs | ||
PERFORMANCE | ||
Gradient | Working on slopes up to 55° in any direction | |
(alarm at 50° and automatic shut-off at 55°) | ||
Specification
Potentiometer speed | 1st gear (low range) |
control (0 to 100%) | Forward and backward 0-4 Km/h |
2nd gear (high range) | |
Forward and backward 0-10.2 Km/h | |
Parking | Yes |
Steering | Skid-steering (support pivot-steering) |
Travelling bias correction | Yes |
Cruise Control System | Yes(One click release) |
PROTECTION AND SAFETY | |
Emergency stop | One-touch shut-off switch |
Over-slope | Automatic waring (Horn+Light) and shut-off |
Headlamp | LED |
Signal loss | Automatic shut-off |
Others | Automatic shut-off if hydraulic oil and lube |
pressure abnomaly | |
ATTACHMENT / FLAIL HEAD (STANDARD) | |
Standard attachment | Flail head |
Oil flow | 84L/min |
Pressure | 250bar |
Rotor speed | 3000rpm |
Front and rear flap | Chain and rubber |
Flails | Y-Flails for grass cutting and light wood |
up to 30mm diameter | |
Rotor width | 1400mm |
Rotor diameter | Grass and shrubs ≤30mm |
Cutting height range | 30mm-90mm (3 positions) |
(via roller adjustment) | flail can be lifted to cut higher than 90mm |
Hydraulic lift | -200mm to 500mm |
Auto-float capacity | Yes (follow ground contour up-down 10°) |
ATTACHMENT / MULCHER | |
Oil flow | 84L/min |
Pressure | 250bar |
Rotor speed | 2500rpm |
Front and rear flap | Chain |
Mulcher width | 1200mm |
Mulcher diameter | ≤100mm |
ATTACHMENT/BRANCH CRUSHER | |
Weight | 260kg |
Max.crushing diameter | 120mm |
Dimensions | 1800 * 90 * 1300mm |
Output power | intelligently allocated hydraulic flow with the host |
Optional Attachments
Application Scenarios
Remote Control Brush Cutters offer the following key advantages when used in areas such as woodland edges and shrubbery:
1. Enhanced Safety
Operators do not need to enter dense vegetation, complex terrain, or potentially hazardous zones (e.g., areas with snakes, insects, steep slopes, or flammable materials). Full remote control significantly reduces personal safety risks.
2. Superior Mobility & Terrain Adaptability
Most remote-controlled brush cutters feature a tracked undercarriage, providing excellent traction and obstacle-crossing capability—easily handling common challenges at woodland edges, such as mud, slopes, gravel, or uneven ground.
3. High-Efficiency Clearing
Equipped with powerful cutting tools (e.g., Y-shaped flail blades, hammers, or dedicated brush-cutting heads), they can quickly clear tall grass, shrubs, and even small-diameter saplings (typically up to 30–50 mm), greatly improving operational efficiency.
4. Precise Operation
Proportional control joysticks enable stepless speed adjustment and fine maneuvering, allowing accurate trimming along woodland boundaries, fences, utility poles, and other obstacles—minimizing accidental damage to surrounding vegetation or infrastructure.
5. Multi-Function Capability
Compatible with various attachments (e.g., mulchers, flail mowers, and branch crushers), these machines support diverse tasks including woodland clearing, firebreak creation, and access path maintenance—delivering true multi-purpose utility from a single platform.
Company Profile
As a subsidiary of Shandong Hongchuan Machinery, Qingdao Huaying Intelligent Equipment Co., Ltd. is dedicated to the research, development, production, and global distribution of compact and mid-sized intelligent outdoor machinery. The company focuses on delivering cutting-edge solutions for turf and vegetation management, with a product lineup that includes advanced remote-controlled lawn mowers, specialized remote-control brush cutters, and the newly introduced 40Pro Yanmar Lawn Mower.
Headquartered in Jining, China, Huaying serves a wide spectrum of applications—from precision landscaping and orchard maintenance to roadside vegetation control. A hallmark of its remote-controlled mowers is the integration of professional-grade tank tracks crafted from high-abrasion-resistant rubber with deep anti-slip treads. This design significantly reduces ground pressure, prevents turf damage, and ensures exceptional stability on slopes and uneven surfaces—making them ideal for sensitive environments such as golf courses, athletic fields, and luxury residential estates.
Complementing this offering, the Remote Control Brush Cutter delivers robust, operator-safe performance for clearing dense underbrush, tall grass, and light woody vegetation in hard-to-reach or hazardous zones.
Newly added to the portfolio, the 40Pro Yanmar Lawn Mower combines reliability and efficiency, powered by a genuine Yanmar diesel engine renowned for durability and fuel economy. Engineered for commercial-grade mowing tasks, the 40Pro features enhanced deck design, ergonomic controls, and optimized cutting performance—bridging the gap between traditional ride-on mowers and fully autonomous solutions. It is particularly suited for parks, municipal green spaces, and large-scale turf maintenance operations where productivity and dependability are paramount.
Together, these products reflect Qingdao Huaying’s commitment to innovation, quality, and sustainable outdoor care solutions tailored to modern operational demands.
Why Choose Us?
Q1: How does your remote control mower ensure operator safety on dangerous terrain?
A: Safety is our top priority. Unlike traditional ride-on mowers, the Smartiger allows operators to work from a safe distance of over 150 meters. It is equipped with an intelligent anti-rollover system: the machine triggers a visual and audible alarm at a 50° slope and automatically shuts down at 55°. Additionally, features such as emergency stop switches, automatic shutdown upon signal loss, and real-time hydraulic pressure monitoring work together to prevent accidents instantly.
Q2: What advantages does your hydraulic system offer compared to competitors?
A: We make no compromises on core components. Our machines are built using a premium international supply chain:
Engine: Genuine YANMAR 3-cylinder diesel engines (EU Stage III compliant), renowned for their durability and low emissions.
Hydraulic Components: We utilize pumps from Bondioli & Pavesi, high-torque travel motors from Poclain, and flail motors from Danfoss.
System Design: Our independent closed-circuit systems for both the tracks and the cutter head ensure smooth, non-interfering operation, even under heavy loads.
Q3: Can a single machine handle different types of vegetation and tasks?
A: Absolutely. The Smartiger is a versatile multi-tool platform. Through quick-change attachments, it can be transformed into:
A Fine Lawn Flail Head: Ideal for grass and shrubs up to 30mm in diameter.
A Forestry Mulcher: Designed to clear trees and brush up to 100mm in diameter, returning biomass directly to the soil.
A Branch Crusher: Specifically engineered to process thick branches up to 120mm in diameter.
This flexibility eliminates the need to purchase multiple specialized machines.
